TitroLine® 5000

Titrator Guide

titrator discount

Price$3,854.00 (US Only)

Option

SKU285230100


In Stock 0 - Available for Backorder

The TitroLine® 5000 automatic titrator combines a syringe burette and pH/mV meter plus integrated intelligence. This intelligence carries out the parameterization of the method for you. The TitroLine® 5000 offers even more features than its predecessor and is even more convenient to use.

  • Overview

    The TitroLine® 5000 does not require special training or deeper knowledge is not necessary for precise and quick results! Use the TitroLine® 5000 to achieve:

    • High-resolution pH/mV-measurement input for pH-, ORP-, silver - and further mV-electrodes
    • Pt 1000 and NTC 30 temperature measurement input for automatic temperature compensation
    • Pre-installed standard methods for FOS/TAC, alkalinity, total acidity in drinks, chloride etc
    • Linear and dynamic titration to equivalence points
    • Titration to pH and mV-end points

    Typical applications of water/wastewater and environmental analysis:

    • pH-value, alkalinity (p+m-value)
    • FOS/TAC (see titration curve and result screen as an example)
    • Total Kjeldahl nitrogen
    • Permanganat index and COD
    • Chloride in wastewater

    Typical applications of food analysis:

    • Salt content (chloride, sodium chloride)
    • pH-value, total acidity in wine, drinks and other food products
    • Ascorbic acid
    • Protein determination (Kjeldahl-nitrogen in milk and dairy products)
    • Iodine and peroxide value

    The available TitroLine® 5000 configurations include:

    Recommended Accessories: Mini-Keyboard 285220410, amber glass reagent bottle 285220590

    Don't forget to add an electrode and an electrode cable!


    Want to learn about YSI's full line of titration systems and features? Visit our titration homepage

    You can also download The Titration Handbook - the comprehensive guide to titration fundamentals and common applications.

  • Specifications
    Accuracy

    according to DIN ISO 8655, part 3: accuracy: < 0.15 %, precision: < 0.05 %

    Certifications ISO 8655, part 6, EMC: 2004/108/EG; safety EG- Directive 2006/95
    Connectivity / Communications 2 × USB (1 USB-A and 1 × USB-B), 2 × RS-232-C
    Display

    3.5 inches - 1/4 VGA TFT graphic color display with 320 x 240 pixels

    Keypad The unit is operated using the keys on the device itself, the controller TZ 3880 and optional PC-keyboard (USB)
    Measurement Method / Channels pH/mV-input with elektrode socket according to DIN 19262. BNC via adapter. Reference electrode 1 x 4 mm socket
    Measurement Range

    0.005-0.025 ml (depending on dosing unit)

    Power 100 -240 V~; 50/60 Hz, power input 30 VA
    Resolution

    8000 steps

    Size

    135 x 310 x 205 mm (W x H x D), including dosing unit, without stirrer, 2.3 kg (without stirrer), 2 kg

  • Accessories

    Titrator and Piston Burette PC Keyboard

    Keyboard for TitroLine® and TITRONIC® Instruments

    Titration Reagent Reservoir

    1000 mL Amber Bottle with Screw Thread

  • How to Order

    Step 1: Order Instrument

    SKU Description
    285230100 TitroLine 5000/20 YSI Autotitrator Basic Unit
    285230610 TitroLine 5000/20 YSI-C Autotitrator Basic Unit*
    285230150 TitroLine 5000/50 Autotitrator Basic Unit
    285230620 TitroLine 5000/50 C Autotitrator Basic Unit

    Step 2: Order Accessories

    SKU Description
    285220410 Titrator and Piston Burette PC Keyboard
    285220590 Titration Reagent Reservoir
    285214232 TitroLine Magnetic Stirrer 10pcs.

    Step 3: Order Electrodes

    SKU Description
    285101260 A7780 pH Electrode
    285100034 N62 pH Electrode
    285100001 N61 pH Electrode
    285092329 N6480 Eth pH Electrode
    285216273 Cu1100 PLH Ion-selective Electrode
    285102413 AgCl62 Metal Electrode
    285102100 AgCl62 RG Metal Electrode
    285102019 Pt62 Metal Electrode
    285102002 Pt61 Metal Electrode

    Step 4: Order Electrode Cables

    SKU Description
    285120217 K1A - Plug cable combination, Coaxial electrode plug, 1 m coaxial cable, DIN instrument plug
    285120225 K2A - Plug cable combination, Coaxial electrode plug, 2 m coaxial cable, DIN instrument plug
    285122456 L1A - Plug cable combination, Coaxial electrode plug, 1 m coaxial cable, DIN instrument plug
    285122464 L2A - Plug cable combination, Coaxial electrode plug, 2 m coaxial cable, DIN instrument plug
    285122653 LB1A - Plug cable combination, Coaxial electrode plug (for BlueLine), 1 m coaxial cable, DIN instrument plug

    Step 5: Order Solutions

    SKU Description
    285138554 L300 - Electrolyte solution in bottles, 1000 ml DURAN® bottle, potassium chloride solution 3 mol/l, sterilized
    285138427 L3004 - Electrolyte solution in bottles, 250 ml DURAN® bottle, potassium chloride solution 3 mol/l, sterilized
    285138440 L3004 cert - Electrolyte solution in bottles, 250 ml DURAN® bottle, potassium chloride solution 3 mol/l, sterilized, with manufacturer certificate
    285138632 L4895 - Buffer solution in FIOLAX® ampoules, 2 x 9 ampoules, buffer solution pH = 4.00 / 7.00, sterilized, with manufacturer certificate, 50 ml plastic bottle KCl solution 3 mol/l

    Step 6: Order Maintenance Items

    SKU Description
    285223007 3/2 Way Valve
    285224303 3-Part Tube Set
    285223718 20 mL Dosing Unit
    285223767 50 mL Dosing Unit

    Step 7: Order Replacement Parts

    SKU Description
    285225840 TM 50 Magnetic Stirrer
    285212217 Titrator and Piston Burette Power Supply
    285215229 Karl Fischer Coulometric Tapper Adapter
    285227103 Replacement Titration Tip with Tube
    285227263 Titration Tip (Blue), 0.7 mm, 5 pcs.
    285220540 Titration Clamp
    285220530 Titrator and Piston Burette Manual Controller
